| SPEC |
STATUS |
| Engine Mode |
ZONGSHEN -ZS154FMI-2 |
| Engine Type |
SINGLE CYLINDER,AIR COOLER |
| Displacement(ml) |
124 |
| Max.Power(kw/r/min) |
6.3(1±10%)/7500(1±5%) |
| Max.Torque (N.m/r/min) |
8.8(1±10%)/5500(1±5%) |
| Compression Ratio |
9.0：1 |
| Bore and Stroke(mm×mm) |
54×54 |
| Ignition method |
CDI |
| Lubrication method |
Pressure spray |
|
10W/40 |
| Starting method |
KICK START |
| Clutch method |
Manual wet multi piece type |
| Gearshift Method |
Normally engaged two-stage transmission with four gears |
| transmission |
Chain |
| spark |
A7TC |
| size ：mm |
1820*750*1130 |
| wheelbase : mm |
1250 |
| seat height : mm |
850 |
| ground clearance : mm |
280 |
| top rake |
21 |
| Minimum turning radius |
2300 |
| gear ratio |
428H/14:41 |
| break |
fr. & re.: disc fr: φ210; re:φ190 |
| break type |
front hand break, rear foot break |
| wheel |
steel wheel, 1.6*17 & 1.85*14 |
| Tire |
fr：70/100-17 re：90/100-14 |
| Fr. suspension |
up side downφ45×φ48×735 |
| Re. suspension |
φ12×350 |
| foot pedal to seat: mm |
530 |
| carb |
PE19 |
| tank capacity |
4L |
| muffler |
aluminum muffler |
| frame |
φ35 material |
| rear swing arm |
Sheet metal forming in one |
| Max load |
100Kg |
| NW |
75Kg |
| Gw |
95Kg |
| packing way |
take off fr. suspension, packed by steel frame and carton |
| packing size |
1400*650*380 |
